At ESPE Manufacturing Co., Inc. we are a technical authority in the production of stamped parts made from electrical insulation and barrier materials such as ITW Formex®, ITW Statex®, and Nomex® as well as Fishpaper and vulcanized fiber. Our capabilities don’t end there – we also stamp parts from other non-metal materials, including a broad range of specialty polymers, aramid papers, and more. Using a variety of stamping methods, including compound die, progressive die, and punch press operations, we manufacture products such as washers, arc chutes, and other insulators in prototype to production quantities. With our inventory of thousands of washer die sets, we can save you money by avoiding the need to build custom tooling.
Our stamping proficiency enables us to punch from continuous strip and coil stock measuring from 0.005" up to 0.250" in thickness. With our robust, quality-driven processes, we uphold close manufacturing tolerances per your specification. We operate a large stamping department with presses rated at up to 40-tons for forming small parts of any geometric complexity. Our tooling specialists maintain our dies in perfect condition to ensure each part is accurate and identical with no variation in dimension or tolerances. Along with prototype stampings and short run stampings, we provide high volume production quantities with fast turnaround services.
As a leading supplier of stamped products to the electrical insulation market, we have a knowledgeable staff and the production assets to consistently produce parts that exceed customer expectations. Contact us directly to learn more about our stamping capabilities or request a quote.
Capability Specifications
- General Capabilities
- Contract
Custom Manufacturing
Fabrication
Production - OEM ‐ Original Equipment Manufacture
Prototype
Intricate
Miniature
- Contract
- Production Method
- Coining
Compound Die
Continuous
Continuous Strip
Die
Forming
Fully Sheared - High Speed
Hot Stamping
Laminating
Open Tooled
Progressive Die
Punch Press
- Coining
- Stamping Features
- Flat
Blanking
Forming - Scoring
Impression Stamping
- Flat
- Part Thickness
.005" ‐ .250"
- Tolerance (+/-)
As per customer specifications
- Materials (Primary)
- ITW Formex GK
ITW Statex
ITW Formex - Fishpaper
Vulcanized Fibre
Nomex
- ITW Formex GK
- Materials (Other)
- Nylon
Copaco®
Kapton®
Teflon®
GPO-3
Forbon®
Polycarbonate
Acetal
Peerless®
Lexan®
Bakelite®
Kydex®
Polypropylene
Phenolic
Acrylic
Nylatron®
PVC - Plexiglass®
Ragpaper
Polyethylene
Glastic®
Rag/Mylar
Vinyl
Delrin®
Mylar®
Nylon MDS
Aramid Paper
PTFE
Acetate
Polystyrene
UHMW
Neoprene
ABS
- Nylon
- Additional Services Provided
- Assembly
Drilling
Embossing
Engineering - Engraving
Lathe Work
Product Development
- Assembly
- Production Volume
Prototype
Low Volume
High Volume
- Lead Times
- 5-15 Days
Quoted on job by job basis - Emergency services available
Rush Services Available
- 5-15 Days
Additional Information
- Industries Served
- Aerospace
Agricultural
Architectural
Automotive
Dental Equipment
Electronic
Food - Machine Tool
Marine
Medical Equipment
Military / Defense
Oil Field
Packaging / Converting
Renewable Energy
- Aerospace
- Industry Standards
ANSI ‐ American National Standards Institute
ASTM ‐ American Society for Testing and Materials (Compliant)
CE ‐ The CE mark (officially CE marking) is a mandatory conformity mark on many products placed on the single market in the European Economic Area (EEA).
CSA ‐ Canadian Standards Association
ISO 9001:2008 ‐ International Organization for Standardization (Compliant)
RoHS ‐ Restriction Of Hazardous Substances (Compliant)
REACH ‐ Registration, Evaluation, Authorization and Restriction of Chemicals
Dodd-Frank
- File Formats
AutoCAD (DWG, DWZ)
BMP ‐ Bit Mapped Graphics
DXF ‐ Drawing Interchange Format, or Drawing Exchange Format
GIF ‐ Graphics Interchange Format
IGES ‐ Initial Graphics Exchange Specification, ANSI file format.
JPG or JEPG ‐ Joint Photographic Experts Group
PDF ‐ Portable Document Format
SolidWorks (SLDPRT, SLDDRW, SLDDRT)
TIFF ‐ Tagged Image File Format
